xradar interop¶

radrs.xradar.open_datatree is a drop-in replacement for xradar.io.open_nexradlevel2_datatree. It returns an xarray.DataTree with the same sweep_N children, the same variable names, and the same dimensions, so code written against xradar generally works by changing the import.

# before
import xradar as xd
dt = xd.io.open_nexradlevel2_datatree(path)

# after
import radrs.xradar as rxr
dt = rxr.open_datatree(path)

The two libraries differ in three places, all on purpose: radial ordering, the representation of gates with no valid measurement, and how cloud sources are reached. Everything else is intended to match, and is checked against xradar in the test suite: sweep count, sweep naming, elevation angles, range geometry, variable sets, and decoded moment values.

What matches¶

Comparing a KTLX VCP-12 volume against xradar 0.12, aligned by azimuth:

"Exact" is literal for the integer-scaled moments: mean, p95, and p99 absolute difference are all 0.0 for DBZH. RHOHV differs by up to 5e-8, which is float32 round-off in the scale/offset decode, not a difference in interpretation.

Radial ordering and sort_by_azimuth¶

xradar sorts the radials within each sweep by ascending azimuth. radrs preserves the order the radials appear in the file, which is the order the radar actually collected them. A sweep starts wherever the antenna was.

rxr.open_datatree(path)["sweep_0"]["azimuth"].values[:5]
# array([167.27, 167.75, 168.27, 168.67, 169.21])   file order

rxr.open_datatree(path, sort_by_azimuth=True)["sweep_0"]["azimuth"].values[:5]
# array([0.19, 0.71, 1.19, 1.76, 2.25])             xradar convention

Pass sort_by_azimuth=True to match xradar. On the volume above the sorted azimuths agree with xradar's to the bit.

Which default you want depends on the work. Sorted is right for plotting and for anything that indexes by azimuth. File order is right when collection sequence matters, such as spotting antenna irregularities or reasoning about the time axis, since azimuth-sorting scrambles it.

Gates with no valid measurement¶

NEXRAD encodes each gate as a byte, reserving the two lowest codes: one for below threshold (the return was too weak to measure) and one for range folded (the return is ambiguous because the target lies beyond the unambiguous range).

radrs decodes both to NaN, meaning "no measurement here". xradar runs them through the moment's scale and offset like any other code, so they come back as numbers at the bottom of that moment's scale:

In every case the below-threshold value is the minimum of that moment's decoded scale and the range-folded value is the next step up. They are ordinary decodes of the two reserved codes, not out-of-band markers. CCORH is the odd one out, with a third value; radrs masks slightly more of it than the two reserved codes alone account for.

Either choice is reasonable. radrs is cleaner for analysis; xradar retains which of the two codes a gate was. In practice the difference is large: on sweep_0 of the volume above, 78.5% of DBZH cells are below threshold. Under xradar those cells hold -33.0, a physically plausible reflectivity, so any mean, histogram, or gradient computed over the raw array is dominated by them. RHOHV's 0.202 is worse, because it looks like an ordinary low-correlation measurement.

Nothing is lost in the other direction. There are zero cells that xradar reports as NaN while radrs reports a value.

Comparing the two libraries¶

Restrict to gates where both report something finite:

import numpy as np

valid = np.isfinite(rs_vals) & np.isfinite(xr_vals)
diff = np.abs(rs_vals[valid] - xr_vals[valid])

Cleaning an xradar array on its own¶

Derive the two reserved values from the data rather than hard-coding them. They are always the two lowest decoded values present:

reserved = np.unique(ds[moment].values)[:2]
cleaned = ds[moment].where(~np.isin(ds[moment].values, reserved))

On Doppler sweeps that reproduces radrs's NaN mask exactly. It is still a heuristic, though, and it over-masks where range folding never occurred. On the surveillance cut of the volume above the two lowest DBZH values are -33.0 and -24.0, and that -24.0 is a real measurement. For RHOHV the same recipe agrees with radrs on 99.93% of cells rather than 100%, and the shortfall is genuine low-correlation gates being thrown away.

Reading the volume with radrs avoids the guesswork, since the distinction is made during decode. The cost is that radrs collapses both codes to NaN, so which one a gate was is not recoverable from its output.

Cloud sources¶

radrs takes a URI directly and fetches it itself:

rxr.open_datatree(
    "s3://unidata-nexrad-level2/2024/03/15/KTLX/KTLX20240315_000217_V06"
)

s3:// defaults to anonymous access, so the public buckets work with no credentials. gs://, az://, file://, and plain local paths are accepted too, along with raw bytes; pass storage_options for private buckets. Only single-volume keys work. The GCS mirror's 6-minute tar bundles are not unpacked and fail at parse.

xradar.io.open_nexradlevel2_datatree needs a local file or an open file object, so reaching the same object means staging it first:

import fsspec, xradar as xd

local = fsspec.open_local(f"simplecache::{uri}", s3={"anon": True})
dt = xd.io.open_nexradlevel2_datatree(local)

Verifying it yourself¶

Two tools in the repo compare the libraries directly. Both need the dev group, which brings in xradar:

uv sync --group dev

scripts/xradar_radrs_bench.py loads one volume through both libraries and prints, per sweep, the radial and range counts, both fixed angles, and for each moment the fraction of gates where both are valid plus the mean, p95, and p99 absolute difference. Moments that agree everywhere collapse to (all obs equal).

Both timings include opening the volume and calling DataTree.load() to materialize all variables in every node before stopping the timer. Remote sources also include fetching the file; use the same local file for both readers to exclude network variability. These are single-run measurements, not repeated or cache-controlled benchmarks.

uv run python scripts/xradar_radrs_bench.py /path/to/KTLX20240315_000217_V06

# or compare a remote volume, letting each library reach it its own way
uv run python scripts/xradar_radrs_bench.py \
  --radrs-source s3://unidata-nexrad-level2/2024/03/15/KTLX/KTLX20240315_000217_V06 \
  --xradar-source https://unidata-nexrad-level2.s3.amazonaws.com/2024/03/15/KTLX/KTLX20240315_000217_V06

It aligns by azimuth internally, so sort_by_azimuth does not need to be set.

notebooks/xradar_radrs_compare.py is the interactive version. Pick a volume, sweep, and moment, and get the two arrays side by side with a difference map, a statistics table (NaN agreement, mean and max absolute difference, percentage within tolerance), an azimuth alignment plot, and the raystack activity summary for the same volume.

uv run marimo run notebooks/xradar_radrs_compare.py

It loads radrs with sort_by_azimuth=True so the side-by-side images line up. The NaN-disagreement row in its statistics table is measuring the below-threshold difference described above, not an error.

maturin develop --release
